The ET Gate Beam Infra Red Blue Eyes V2 is a reliable active infra-red single beam kit designed to provide a range of +/- 10m, ensuring effective gate security and access control. With an infra-red frequency of 1,92kHz and a wave length of 940nm, this kit operates on a power supply of 12 to 24V AC or DC, making it suitable for various installation scenarios. It operates at an operating current of RX = 15mA and TX = 30mA, with a relay load rating of 1A @ 30V max. Additionally, it offers a wide operating temperature range of -20°C to 70°C, ensuring consistent performance in diverse environmental conditions.
Specifications and Features:
- Active infra-red single beam kit with a range of +/- 10m
- Infra-red frequency: 1,92kHz
- Power supply: 12 to 24V AC or DC
- Wave length: 940nm
- Operating current: RX = 15mA, TX = 30mA
- Operating temperature: -20°C to 70°C
- Relay load rating: 1A @ 30V max
